Posts and struts
Posts and struts
FOUR-SQUARE POSTS
Four-square post is a universal post, applicable to all types of fencing, gates and doors offered by our company. It has a strong structure. It is available, like all types of fencing offered by our company in all, more than 200 RAL colours.
Four-square steel post surface is treated with zinc coating or quality powder coating, completed by a plastic cap with an appropriate covering strip to attach to the panels.
SPECIFICATION (TECHNICAL PARAMETERS)
Post dimensions: 40 × 60 × 2 mm.
Post height: 1500 mm, 1700 mm, 2000 mm, 2300 mm, 2500 mm, 2700 mm.
POSTS SUITABLE FOR FENCING MESH
POST A-1
Thanks to its shaped profile, the A1 type posts with circular cross-section are the best type for fixing welded fencing mesh. Surface treatment with double-sided galvanizing and plastic coating ensures a long service life. They are suitable for any terrain, slopes or height differences. The mesh is fastened to the post with stainless steel clips using clamping pliers.
Available in dark green (RAL 6005).
The post also includes a PVC cap.
It is used together with the side strut (UNI BPL).
SPECIFICATION (TECHNICAL PARAMETERS))
Post diameter: 50 mm.
Post height: 1500 mm, 1800 mm, 2000 mm, 2200 mm, 2500 mm, 2750 mm, 3000 mm.
Strut height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
POST B-1
Thanks to its simple tubular construction and very simple fastening system, the B1 type circular cross-sectional posts are the most suitable for fastening square mesh. Surface treatment with double-sided galvanizing and plastic coating ensures a long service life. They are suitable for any terrain, slopes or height differences.
Available in dark green (RAL 6005).
The post also includes a PVC cap.
It is used together with the side strut (UNI BPL).
Specification
Post diameter: 48 mm, resp. 38 mm.
Post height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
Strut height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
SIDE STRUT TYPE AB
The side strut of type AB is of circular diameter and is used with posts of types A1 and B1. Like these posts, its surface is treated with double-sided galvanizing and plastic coating.
Available in dark green (RAL 6005).
The side strut includes a holder and a hook bolt to be fixed to the post.
Specification
Side strut height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
POST ZN
Due to its simple tubular construction and very simple fastening system, ZN type circular cross-section posts are the most suitable for fastening the square mesh. The surface treatment with double-sided galvanizing ensures protection against corrosion. They are suitable for any terrain, slopes or height differences.
The difference between the ZN and B1 post lies in the absence of plastic coating.
Available in dark green (RAL 6005).
The post also includes a PVC cap.
It is used together with the side strut (UNI BPL).
SPECIFICATION (TECHNICAL PARAMETERS)
Post diameter: 48 mm, resp. 38 mm.
Post height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
Strut height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
SIDE STRUT TYPE ZN
The side strut of type ZN is of circular diameter and is used with the posts of ZN type. Like these posts, its surface is treated with double-sided galvanizing to ensure its corrosion protection.
Available in dark green (RAL 6005).
The side strut includes a holder and a hook bolt to be fixed to the post.
SPECIFICATION (TECHNICAL PARAMETERS)
Side strut height: 1500 mm, 1750 mm, 2000 mm, 2200 mm, 2300 mm, 2400 mm, 2500 mm, 2600 mm, 3000 mm.
